WJ-400A melt flow rate tester / melt index tester
Product type: WJ-400A supplier: Chengde Wanji Instrument Manufacturing Co., Ltd.
Product price: face to face
Product Description:
Melt Flow Rate Meter Details: Melt Index Meter, Melt Index Meter, Melt Flow Rate Meter
Product uses:
WJ-400A Melt Flow Rate Meter is mainly used to measure the melt mass flow rate of thermoplastic resins. It is suitable for testing engineering plastics such as polycarbonate and polysulfone with higher melting temperature and materials with lower melting temperature such as polyethylene, polystyrene, polypropylene, ABS resin and polyformaldehyde resin. It is widely used in plastics. Production, plastic products, petrochemical industry and related institutions, research institutions and commodity inspection departments.
Product Description:
This machine adopts a new generation of artificial intelligence instrument to control temperature and the output control of two-bit time relay. The instrument has short constant temperature period and minimal overshoot. The temperature control part adopts the "burnable" SCR module, so that the temperature control accuracy and product stability can be effectively guaranteed. For user"s convenience, this type of instrument can be controlled in time, manual two cutting methods into one (cutting interval and cutting time can be set arbitrarily)
This machine is a Taiwanese model with high degree of intelligence and automation. It has a wide range of applications, high heating speed, high precision and stable performance. It is an ideal test and teaching instrument for plastic raw materials and plastic products manufacturers, as well as for quality inspection and inspection institutes and colleges.
Test parameters:
Scope of measurement: 0.1-400.00g/10min (MFR)
Temperature range: -400 C at room temperature.
Temperature control accuracy: + 0.2 C
Timing accuracy: 1S
Load: full load
Cutting mode: manual and time control.
The inner diameter of the barrel is 9.550mm + 0.025mm.
Material cartridge length: 160mm
Die: the material is tungsten carbide, long: 8.000mm + 0.025mm inner diameter: 2.095mm + 0.005mm
Power: 0.45KW
Power: AC220V, 50Hz
Instrument size: 400mm * 500mm * 600mm
The net weight of instrument is 60Kg
Instrument configuration:
Serial number
Name
Company
Number
One
Host
platform
One
Two
Weight
set
One
Three
Scraper
branch
One
Four
piston
branch
One
Five
funnel
branch
One
Six
Die cleaning rod
branch
One
Seven
Cartridge cleaning rod
branch
One
Eight
Level
branch
One
Nine
Footing
branch
Four
Ten
Power cord
root
One
Eleven
Packing list
share
One
Twelve
Instructions
share
One
Thirteen
Certificate
share
One
Fourteen
The following blank
