SENS電池充電器DCT24-150-4652

SENS電池充電器 DCT24-150-4652

泉州市海科恩機械設備有限公司

TEL:

IQ detail: EnerGenius IQ dual microprocessor charger/DC power supply with integrated battery check system. Input: 230/240 VAC, 50/60 Hz,1-phase.Output: 24VDC nom. 150A with 30mv on battery. On battery ripple measured at the terminals of a battery rated in AH > 4 times charger’s amp rating. Line & load regulation +0.25%. Features: LED mimic panel & 2 x 20 backlit LCD, float, equalize and auto-equalize charging modes, 1% accuracy digital volt and ammeters, 5% accuracy AC voltmeter, battery temperature compensation, battery check system, computer based expert system. Alarms: Single summary, and individual form C alarm relay contacts for: AC fail, charger fail, low battery voltage, high battery voltage, ground detection, battery chk. fail, end-of-discharge, and  AC pilot relay. Front panel adjustment of all parameters, with two different levels of user access. Safety and reliability: CE marked/C-UL, backwards battery protection(audible), seismic zone 4 tested(wall mnt), 2-pole input and output breakers, precision current limit, over temperature protection, ANSI C62.41 Cat. B surge protection, -40C to +50C operating temp. Dual processors offer fault-resilient operation and redundant, selective overvoltage protection. Construction: Printed circuit cards with high reliability zero potentiometer SMT design and conformal coating and rugged steel housing. Material: 16 GA(.0598) thick sheet 304 Stainless Steel(SS).IQ 細節：EnerGenius IQ 雙微處理器充電器/直流電源，帶集成電池檢查系統。輸入：230/240 VAC，50/60 Hz，1 相。輸出：24VDC 標稱。 150A，電池為 30mv。在額定 AH > 4 倍充電器安培額定值的電池端子上測量的電池紋波。線路和負載調整率 +0.25%。特點：LED 模擬面板和 2 x 20 背光 LCD、浮動、均衡和自動均衡充電模式、1% 精度數字電壓和電流表、5% 精度交流電壓表、電池溫度補償、電池檢查系統、基于計算機的系統。警報：單個摘要和單的 C 型警報繼電器觸點，用于：交流故障、充電器故障、電池電壓低、電池電壓高、接地檢測、電池 chk。故障、放電結束和交流引導繼電器。前面板調整所有參數，具有兩種不同級別的用戶訪問權限。安全性和可靠性：CE 標志/C-UL、反向電池保護（聲音）、地震區 4 測試（墻壁 mnt）、2 極輸入和輸出斷路器、精密電流限制、過溫保護、ANSI C62.41 Cat. B 浪涌保護，-40C 至 +50C 工作溫度。雙處理器提供故障恢復操作和冗余、選擇性過壓保護。結構：印刷電路卡具有高可靠性零電位計 SMT 設計和保形涂層和堅固的鋼外殼。材料：16 GA(.0598) 厚板 304 不銹鋼 (SS)。

美國KTI儲能器ACB30C-12P-NT-4

美國SENS電池充電器NRG24-10-HC

SENS電池充電器Q024025PG512C

FILTERED BATTERY CHARGERALSTOMDCT24-25-A642

TURBINETYPHOON4.9MW/5.2MWRM247W

SENS電池充電器 DCT24-150-4652

可以選用替代型號：Q024025PG512C(wallmnt/50Hz)

DCT24-150-4652  G512C(wall mnt/50-60Hz)

DCT24-25-A642 Q024025PG512C(wall mnt/50/60Hz)

美國KTI蓄能器
