Applications: | Features: |
Fiber Amplifier Fiber Laser Fiber Instrument |
Parameter | Unit | Specification |
Part No. | - | LQ-SMPLP-W-PW-P-FT-PF-C |
Pass Wavelength | nm | 900~1000 |
Reflection Wavelengt | nm | 1020~1120 or 1500~1600 |
Pass insertion Loss | dB | <0.6 |
Isolation | dB | >30 |
Return Loss | dB | >50 |
PDL | dB | <0.15 |
Power Handling | W | 1,3,5 |
Tensile Load | N | <5 |
Fiber type | - | Hi1060 |
Operating Temperature | °C | 0~+70 |
Storage Temperature | °C | -40~+85 |
Dimensions | mm | φ5.5 × L35 or L70*W12*H9 |
Order Information：
LQ-SMPLP-W-PW-P-FT-PF-C
W:Wavelength, 9806=980pass/1064reflect,9855=980pass/1550reflect
PW: Output power in W, example: 5-5W,3-3W,1=1W
P:package,1=φ5.5 × L50,2= L70*W12*H9
FT:fiber type,1=hi1060
PF: Pigtail fiber, 0=250um,1=900um,3=3mm
C:Connector,FU=FC/UPC,FA=FC/APC,SA=SC/APC,,SU=SC/UPC,LA=LC/APC,LU=LC/UPC
